high power wirewound resistor
1000 Watt fester Aluminium-Schalenbremswiderstand Hochleistungs-Wirewound-Widerstand mit keramischer Komposition
1000-W-Bremswiderstand mit Aluminiumgehäuse und einem Bereich von 1 Ω bis 30 kΩ. Verfügt über eine drahtgewickelte Konstruktion für Haltbarkeit, ±5 % Toleranz und ISO9001/TUV/ROHS-Zertifizierungen. Ideal für die industrielle Automatisierung, Wechselrichterbremsung und Hochleistungsanwendungen.
2000W Ripple-Bremswiderstand mit einstellbarer Drahtwicklung für Hochleistungsanwendungen
Products Show Ripple braking wirewound 2000W variable resistorRated Power : 2000W Size: 430mm length & 70mm diameterResistance value：1RJ 2RJ 3RJ 4RJ 6RJ.......10KRJType : AdjustableFeatures:1.Resistance surface is paint, power range is wide 2.Excellent high temperature load performance 3.Full welded structure4.High reliability RX20 Fixed Types you may also like Company Profile Factroy Informations:Sichuan Qixing Elctronics Co., Ltd is a specialized enterprise engaging in
Hochleistungs-Wirewinding-Widerstand 5W 10W 20W 100W 47 50 100 Ohm Keramikzementwiderstand
product name: Cement resistor 5W 10W 0.25R 0.5R 3R 27R 12R 100R 5% ceramic resistor product description: Cement resistor is a resistor sealed with fire-resistant clay, which involves winding the resistance wire onto a non alkaline heat-resistant porcelain piece, wrapping it with heat-resistant, moisture-resistant, and corrosion-resistant materials, and placing the wire wound resistor body into a square porcelain frame, sealed with special non combustible heat-resistant cement
RX24 50w 100RJ Gold Aluminium Gehäuse Wirewound Widerstand Hochleistung
product name RX24 50w 100RJ Gold Aluminum Housed Wirewound resistor High Power Product Description The surface of the gold aluminum shell resistor has a heat dissipation groove, small size, large power, high temperature resistance, strong overload capacity, weather resistance, high precision, standard low inductive resistance, high stability, strong architecture, and its flexibility is good for multiple combination options, which is conducive to mechanical protection and easy
Hochleistungs-Wirewound-Potentiometer rotierende Rheostat-Disk Keramikvariabler Widerstand 25W 50W BC1-50W BC1
Variable rheostat 50w Data list: Electrical Characteristics: Range of nominal resistance.........1Ω~10KΩ Resistance tolerance.........±10% Terminal resistance.........≤0.2% or 1Ω Insulation resistance.........≥100mΩ(500Vdc) Max heating temperature.........350° Environment Characteristics: Rated power.......................50W-500W @ 85°,or @ 400 Temperature range.................-55°~400° Vibration.........................10~200HZ, 40m/S2, 3h ΔR≤±3%R Thermal cycles...........
BONENS RXG20 500W Hochleistungs-Wickelbremswiderstand mit Keramikrohrgehäuse und 5% Toleranz
Product Description Ripple Tube Painted Braking Resistor 500W High Power wirewound Resistor Namebraking resistorModelRXG20Performancehigh powerShapeCylindrical ceramic tubeMaterialWirewoundRated power500 WResistance1ohms~5K ohmsResistance tolerance±5%DiameterD=50mmLengthL1=330mmMounting bracketsIncludingNon-standard sizeCan be customizedAdjustable typeCan be offered Packing & Delivery Company Profile Sichuan Qixing Electronics CO.,LTD specialize in potentiometers, resistors
5000W Hochleistungsbremswiderstand mit lackiertem Keramikrohr und anpassbarer Größe
Products Show 5KW High Power wirewound Braking Resistor 5000WRated Power : 5000W Size: 500mm length & 100mm diameterResistance value：1R 2R 3R 4R 6R.......10KRResistance tolerance: ±1%(F), ±2%(G), ±5%(J), ±10%(K)Type : Fixed Features:1.The surface of the resistor is coated with insulating resin paint, and the materials are all non-toxic and environmentally ROHS products 2. Adopt vertical corrugated winding, which can reduce parasitic inductance, enhance heat dissipation
High Power Wirewound-Widerstand 25w Grüner Metall-Aluminium-Hüllen-Widerstand
product name High power Wirewound Resistor 25w Green metal aluminum case resistor Product Description The surface of the gold aluminum shell resistor has a heat dissipation groove, small size, large power, high temperature resistance, strong overload capacity, weather resistance, high precision, standard low inductive resistance, high stability, strong architecture, and its flexibility is good for multiple combination options, which is conducive to mechanical protection and
Verstellbare Wirewund-Widerstände 100w Hochspannungs-Keramikwiderstände
Rx20 adjustable wirewound resistors 100w high power ceramic resistor PRODUCT NAME RX20 High Power Aging Load Corrugated Wire Wound Porcelain Tube Resistor 10w~10000watt PRODUCT INTRODUCTION Specifications: Power range 10W-10000W. Voltage range- 0.5KV-10KV. Resistance Range 1R-1KR. Pressure- AC2500V / 1min50Hz. IP rating IP00. Rated temperature- 375 ℃, short-term / repeat 40% ED. Thermal equilibrium time constant τ = 200s. Advantages High voltage. Packing-- carton packaging.
