rotary potentiometer

product name: 15 * 17 metal knob 13 * 17 audio knob potentiometer cap aluminum alloy knob silver black gold specification:13*17mm 17*17mm 21*17mm 26*17mm 30*17mm 35*17mm 40*17mm product description: 1. Aluminum alloy button knob, adopting concentric circular CD pattern, with a linear appearance design; 2. Suitable for a wide range of electronic and electrical products, suitable for all rotary potentiometers and conversion switch timers, as well as other electric guitars,

product name R16P2S 500K 4mm Carbon Resistant Dimmer Light Potentiometer Push Push Switch Home Appliance Industrial Lighting Control product description WH116AK is a high-performance carbon film rotary potentiometer with a press switch function, widely used for dimming, speed regulation, and volume adjustment. Resistance value range: 1k Ω~2M Ω, allowable deviation of resistance value ± 18%, rated power: 0.2W, mechanical life: 50000 times. The main structure of WH116AK

product name RV17 B1K B10K B50K single-link audio amplifier with switch volume adjustable rotary potentiometer 5 pins product description Total resistance value: 500 Ω -1M Ω Total resistance tolerance: ± 20% Impedance characteristic types: A, B, C, D Noise: Less than 100mV at 20 mmc Insulation impedance: More than 10M Ω at DC 250V Voltage withstand: 1 minute at AC 250V Residual resistance value: Term. 1-2: Less than 10 Ω Term. 2-3: Less than 10 Ω Synchronous error (dual

Product Description Specification item value Model Number WX110(010) Type Rotary Potentiometer Place of Origin China Brand Name BONENS Technology Wirewound Resistance 100 ohm~22K Resistance Tolerance ±5% Rated Power 1W Operating Temperature -55°C~ 125°C Tolerance ±5% Diameter 29mm Built in Switch None Rotation 300° Resistive Material Wirewound Termination Style Solder Lug Actuator Type Slotted Bushing Thread M10 x 1 Shaft Size 0.236" (6.00mm) Number of Turns 1 Company Profile

RVQ24 RVQ24YN RVQ24YN03 20F B502 20S B5K 5K long-life carbon film potentiometer switch product name: ong-life industrial control panel potentiometer Single turn game console potentiometer rotary potentiometer RVQ24 RVQ24YN03 Carbon film single turn potentiometer Long Life 24mm Diameter, Single-Turn, Carbon Panel Controls RVQ24 potentiometer metal carbon membrane potentiometer Rvq24yn03 20S B502 longevity potentiometer RVQ24 RVQ24YN RVQ24YN03 product description: RVQ24YN03

P16 P16NP Single Turn Knob Potentiometer with Switch Sealed potentiometer WI1609 cermet 1W 10% trimmer potentiometer product name: P16 P16NP Single Turn Knob Potentiometer with Switch Sealed potentiometer WI1609 cermet 1W 10% trimmer potentiometer product description: The P16 is a revolutionary concept in panel mountedpotentiometers. This unique design consists of a knobdriving and incorporating a cermet potentiometer. Only themounting hardware and terminals are situated on

RVQ24YN03 rotary potentiometer 10k with ip67 waterproof Products datasheet: 1.) Mechanical specifications: a.) total rotational angle: 300±10° b.) rotational torque: 20~200gf.cm c.) click position is available d.) rotation stop strength: 8kgf.cm Max e.) residual resistance: Max 10 ohm 2.) Electrical specifications: a.) total resistance range: 500 ohm = 1M ohm ± 30% b.) resistance taper: A, B, C, D c.) power rating: 0.2 w d.) Max. operating voltage: AC 500 V e.) rotational

product name WXD4-23 100ohm Multi-turns 3W wirewound 101 potentiometer b100k 3W 1K 2K2 3K3 4K7 5K6 10K 15K 22K 47K Spot resistance value: 100 Ω 220 Ω 330 Ω 470 Ω 560 Ω 680 Ω 1K 1K5 2K2 3.3K 4.7K 5.6K 6.8K 10K 100K 22K 33K 47K 15K product description: Model: wxd4-23-3w Attribute: Multi turn precision potentiometer Packaging: 1 box/5 pieces 1, Environmental conditions for use: Environmental temperature: -50~+100 ℃; Relative temperature: 98% at a temperature of+40 ℃; Atmospheric

product name WX110 100 ohm 1W potentiometer single coil wire wound potentiometer WX110 010 potentiometer product description The WX110 potentiometer adopts a single-turn wire-wound structure design.Its working principle is based on the adjustment principle of wire-wound resistors. By changing the position of the resistor's contact point on the winding wire, the resistance value is changed.This kind of potentiometer is generally used for variable resistance adjustment in
